2024 Big Tex 14LP-16 - 9161
Get in Touch
AT A GLANCE
NEW LOWER PRICE Big Tex Super Low Dump Trailer With 24" High Sides 83" WIDE DECK X 16' LONG WITH 24" HIGH SIDES GVW: 14,000 LBS EMPTY WEIGHT: 4,811 LBS PAYLOAD: 9,189 LBSSTANDARD FEATUR
Industry
Trailer
Make
Big Tex
Category
Dump Trailers
Year
2024
Model
14LP-16
Trim
Base
Stock
9161
Subcategory
Dump Trailers
Description
2024 Big Tex 14LP-16
14LP
Heavy Duty Ultra Low Profile Dump
Tough as nails for the toughest, most demanding projects, the 14LP Heavy Duty Low Profile Dump Trailer is designed for the construction workers and those transporting large quantities of materials or equipment. And while it’s built to handle heavy-duty hauling tasks, it’s also packed with features to make the toughest jobs easier such as an ultra-low profile deck and side step to provide convenience and ease of use during loading, unloading, and transportation of materials.
Dealer Notes
83" WIDE DECK X 16' LONG WITH 24" HIGH SIDES
GVW: 14,000 LBS EMPTY WEIGHT: 4,811 LBS PAYLOAD: 9,189 LBSSTANDARD FEATURES + OPTIONS:
TANDEM 7K SPRING ELECTRIC BRAKE AXLES WITH EZ LUBE HUBS
12" NEVER ADJUST ELECTRIC BRAKES
ADJUSTABLE 2 5/16" BALL COUPLER OR PINTLE RING
12K BOLT ON DROPLEG JACK
12 VOLT ELECTRIC HYDRAULIC LIFT SYSTEM
12 VOLT DEEP CYCLE MARINE BATTERY
SCISSOR LIFT POWER UP + DOWN
110 VOLT CHARGER MAINTAINER
12 VOLT CHARGE WIRE WITH CIRCUIT BREAKER
MESH TARP SYSTEM INCLUDED
2 WAY REAR COMBO GATE / BARN - SPREADER
6' SLIDE OUT REAR H/D RAMPS
4 H/D D-RING TIE DOWNS
2 REAR DROP DOWN STABILIZER LEGS
ST235/80R16 LRE RADIAL TIRES
BLACK MODULAR STEEL 16" 8 LUG WHEELS
SPARE TIRE CARRIER MOUNTED C/S FRONT
7 WAY MOLDED FRONT RV STYLE PLUG
LED RUBBER MOUNTED LIGHTING
2 SIDE MOUNTED ACCESS STEPS
DUMP ANGLE 45*
8.3 CUBIC YARD CAPACITY1 YEAR STANDARD + 3 YEAR STRUCTURAL LIMITED WARRANT
Info
Condition
New
Location
Trailers LLC
VIN
16V1D2121R5349161
Dry Weight
4,811 lbs
Color
Black
Hitch Type
Adjustable 2-5/16" Ball Coupler or Pintle Ring
Axles
Tandem 7K Spring Electric Brake Axles with EZ Lube Hubs
Length
16'
Width
83"
Height
24" high sides
Wheels
16" Black Modular Steel 8-Lug
Tires
ST235/80R16 LRE Radial
Rear Door
2-Way Rear Combo Gate / Barn-Spreader
Gvwr
14,000 lbs
Axle Capacity
7,000 lbs per axle
Payload Capacity
9,189 lbs
Stock Capacity
8.3 cubic yards
Load Type
Dump Trailer
Specifications
GVWR
14000 lbs
Dry Weight
3555 lbs
Length
Bed: 14'
Width
Bed: 83"
Tongue
8" Seamless I-Beam Integrated w/ Frame (10#) | Length: 51-1/8"
Axles
2 - 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs
Brakes
Forward Self-Adjusting Electric Brakes on Both Axles
Suspension
Multi-Leaf Slipper Spring w/ Equalizer
Coupler
2-5/16" Ball, Adjustable Demco EZ Latch Coupler
Safety Chains
3/8" Grade 70 w/ Safety Latch Hook (2 ea)
Frame
8" Seamless I-Beam (10#)
Crossmembers
3" Channel on 16" Centers
Floor
10 Gauge Smooth Steel
Fenders
9" x 72" 14 Ga. Diamond Plate Double Broke
Lights
Recessed, Grommet-Mounted L.E.D. Lighting
Notes
GAWR (Ea. Axle): 7000 lbs | Cargo Capacity: 9750 lbs | Wiring: Sealed, Modular Cold-Weather Wiring Harness
Tires
ST235/80 R-16 Load Range E Radial Tires
Wheels
Black Mod Steel
Battery
12V Deep Cycle
Gate/Door
Rear Combo Gate (Barn Doors & Spreader Gate)
Step
Convenient Side-Step to Access Top Rail
Top Rail
3"x 2" Rectangular Tubing
