2026 Nordtek Trailers DO102x25-16HDGN - 0555
Get in Touch
AT A GLANCE
NORDTEK ALUMINUM TRAILERS DOGN102X25-16KHD 102" WIDE X 25' LONG 8 TON ALUMINUM DECKOVER GOOSENECK 20' FLAT DECK + 5' SELF CLEANING BEAVERTAIL AND 2 PIECE SUPER RAMPS GVW: 16,000 LBS EMPTY WEIGHT: 4,
Industry
Trailer
Make
Nordtek Trailers
Category
DeckOver Trailers
Year
2026
Model
DO102x25-16HDGN
Trim
Base
Stock
0555
Subcategory
DeckOver Trailers
Description
2026 Nordtek Trailers DO102x25-16HDGN
14K Tilting Deckover Trailer
Features may include:
- 8 bolt wheels
- 6 inch channel lace rail
- 4 inch channel crossmembers, 16 inch spacing
- 2 1/2 inch rub rail and 4 inch stake pockets along the sides
- Easy lube hubs
- 12,000 lb. jack
- Dual cylinder for tilting deck
- LED lighting
- Braided wiring harness for extra durability
- 2 5/16 inch adjustable coupler
- Brown all-weather pressure-treated deck boards
- 7 inch guard rail along the front
- Checker-plated wheel covers
- Deep toolbox
- Winch plate
- Tilting Deck
Optional Add-ons
- Aluminum rims
- Spare tire
- Hydraulic jack
- Salt shield
- 8,000 lb. axles
- Pintle hitch
- 14 ply tires
Dealer Notes
NORDTEK ALUMINUM TRAILERS DOGN102X25-16KHD 102" WIDE X 25' LONG 8 TON ALUMINUM DECKOVER GOOSENECK
20' FLAT DECK + 5' SELF CLEANING BEAVERTAIL AND 2 PIECE SUPER RAMPS
GVW: 16,000 LBS EMPTY WEIGHT: 4,200 LBS PAYLOAD: 11.800 LBS
TANDEM 8K ELECTRIC BRAKE SPRING AXLES WITH EZ LUBE HUBS
12" ELECTRIC BRAKES ALL WHEELS
MULTI LEAF SLIPPER SPRING SUSPENSION
2 5/16" ADJUSTABLE GOOSENECK COUPLER
DUAL 12K DROPLEG LANDING GEAR STYLE JACKS
ST235/80R16 LRG 14 PLY RADIAL TIRES
16" ALUMINUM 8 LUG WHEELS
SPARE TIRE CARRIER MOUNTED IN GOOSENECK
ATP TOOL BOX MOUNTED IN BETWEEN THE RISERS
EXTRUDED ALUMINUM PLANK DECKING
STAKE POCKETS WITH RUB RAIL FULL LENGTH
2 PIECE ALUMINUM SPLIT SUPER RAMPS WITH SPRING ASSIST
2 REAR DROP DOWN STABILIZER JACKS
7 WAY RV STYLE MOLDED FRONT PLUG
MOLDED SEALED WIRING HARNESS
LED DOT COMPLIANT LIGHTING
RECHARGING BREAKAWAY SYSTEM
2 SIDE MOUNTED CLEATED STEPS
5 YEAR MANUFACTURERS LIMITED WARRANTY
Info
Condition
New
Location
Trailers LLC
VIN
2ND102250TA000555
Dry Weight
4,200 lbs
Color
Aluminum
Hitch Type
2 5/16" Adjustable Gooseneck Coupler
Axles
Tandem 8,000-lb Electric Brake Spring Axles with EZ-Lube Hubs
Length
25'
Width
102"
Suspension
Multi-Leaf Slipper Spring
Wheels
16" Aluminum 8-Lug Wheels
Tires
ST235/80R16 LRG 14-Ply Radial
Rear Door
2-Piece Aluminum Split Super Ramps with Spring Assist
Floor
Extruded Aluminum Plank Decking
Gvwr
16,000 lbs
Axle Capacity
8,000 lbs each
Payload Capacity
11,800 lbs
Trailer Material
Aluminum
Load Type
Equipment
Nose Type
Gooseneck
Specifications
Notes
Deck Size: 102 in x 25 ft (20+5 Beavertail) | Jack: 2 x 12,000 lb.
Height
Deck: 33 in
Floor
2 in x 8 in
Hitch Size
25K 2-5/16 in GN coupler
Axles
8,000 lb. each
Tires
10 ply ST235/80R16
Brakes
Electric: 2 axle
GVWR
16,000 lb.
Max Load
12,392 lb.
Dry Weight
3,608 lb.
